Model D201

Speed increasing gearbox

Speed Increaser: Model D201

Features include an aluminum case (similar to the D101) with extra width for additional input and output shaft configurations, increased sump size for higher horsepower and cooling capacity, engine or anti-engine rotation.

Typical Applications:

Rotary Screw Compressors, Centrifugal Water Pumps

Specifications

Ratios: 1.1 : 1 through 1 : 2.5
Rotation: Engine/Anti-Engine
Max Horsepower: 150 HP
Center Distance: 6″
Overall Size: 16.5″H x 12.4″W x 11″D
Weight: 150 lbs approx.
