Engineering Support
Specifications
- Custom Gearbox Design & Build Services
- Gearbox Repair and Remanufacturing
- Finite Element Analysis (FEA)
- Prototyping & Validation Services
- Gear Sizing Software and Analysis
- Fixture and Tooling Design
- Process Design
- PPAP’s (Preproduction Approval Process)
- Program Management
- Reverse Engineering
- Technical Documentation Support
- Inspection – Coordinate Measurement Machine (27in. x 40 in. x 24in.)
- Inspection – CNC Gear Inspection (Dia. 11.5in. x length 23.5in.)
- Rj Link Oil Recommendations – Contact factory for information
- Gearbox Application Data Sheet
Gearbox Expertise:
- Design and manufacture all types of gearbox assemblies; Speed Increasers, Speed Reducers, Transfer Cases, Right Angle and Planetary Gearboxes.
- Provide expertise in the remanufacturing and overhaul of gearboxes.
- Gear grinding: Up to 15.74″ diameter. AGMA class 5 per the new AGMA 2015 inspection standard. Previously considered AGMA class 12 per the old AGMA 1000-A88 standard.
- Alliances with local manufacturers having gearing experience allows us to offer our customers major OEM experience with small company responsiveness.
CAD Platforms:
- Solidworks
